Fiber Laser Welding Machine.

Application: Fiber laser Welding are mostly used in automotive, electrical, tools &

tooling, medical, surgical, Jewelers & fashion accessories, kitchenware & bath fittings

for Welding.

Fiber Laser Welding Machine Specifications :

Model SML-FW1o00 / FW1500/ FW2000 W

Laser Frequency 5 Hz to 50 Hz

Laser Wave Length 1 064nm

Cooling System Water Cooled

Running Environment 10 - 35 Degree Celsius, Humidity 20-80 %

Output Power Stability <2%

Output Fiber Length 10 M

Working Voltage 415V AC /50Hz

Beam Quality 1:1

Cooling Water Temperature 20-25 Degree Celsius

Average Consumed Power 2000-4000W

Warranty time Whole machine for 1 years (Fiber 2 Years )

Rotary Axis Optionally

Delivery time 15 days

Feature's :

Ø The system is mainly composed of a laser unit and a welding unit.

Ø Hand-held welding, taking into account the flexibility, high efficiency and high weld

quality of laser welding.

Ø The process of welding is non contact type, very clean process & dose not cause

physical stresses.

Ø Modular design and layout of the overall equipment, beautiful and easy to maintain

and debug.

Ø IPG / RAYCUS / JPT / MAX Photonics Laser Source

Ø High system flexibility, compatible with a variety of models, and short changeover

time.

Ø The internal design is dexterous, and the good interactive control system expands the

tolerance range of the machined parts and the weld width, solves the disadvantage of

small spot size, and welds are better formed.

Ø The shape is light, the body engineering design method is adopted, and the grip is

comfortable; the hand is easy to control, and the operation is simple and easy to use.

Ø With multiple safety alarms, the light is automatically locked after the workpiece is

removed, and the safety is high.

Ø Beautiful weld seam, fast speed, no consumables, no weld marks, no discoloration, no

need for post-grinding.

Ø Can be equipped with a variety of angle nozzles to meet the welding needs of different

products.

Materials to be Welded : Aluminum, Brass and copper, Tungsten, Stainless Steel, Mild

Steel, Titanium.
